HPLC HbA1c Test Analyzer Medical Blood Testing Use High Effciency

Name: HPLC HbA1c Test Analyzer Medical Blood Testing Use High Effciency
Brand: LABNOVATION
Price: 1 USD

Brand Name : LABNOVATION

Model Number : LD-600

Certification : IFCC, NGSP, CE

Place of Origin : Shenzhen, China

MOQ : 1 Unit

Price : Negotiation

Supply Ability : 100 Units/Day

Delivery Time : 10-15 working days

Packaging Details : Carton Size: 480mm×480mm×615mm, Gross Weight: 28kgs

Name : HbA1c Analyzer Medical Blood Testing Use High Effciency HPLC HbA1c Test Analyzer

CV Value : <2%

Method : HPLC (High Performance Liquid Chromatography)

Test Speed : 65 seconds/test

Load Compacity : 110 Samples

Emergency Position : 1 STAT

Contact Now

HbA1c Analyzer Medical Blood Testing Use High Effciency HPLC HbA1c Test Analyzer

HbA1c Analyzer Medical Blood Testing Use High Effciency HPLC HbA1c Test Analyzer is the fully automated high performance liquid chromatography analyzer. It integrates both diabetes monitoring and abnormal hemoglobin detection on a fully automated platform. Quickly detect hemoglobin such as HbA1C, HbA2, HbF, etc. with a single touch of the touch screen. Suitable for laboratories and clinical clinics with 10-50 daily samples.

Specification

Name	HbA1c Analyzer Medical Blood Testing Use High Effciency HPLC HbA1c Test Analyzer
Model	LD-600
Methodology	High-Performance Liquid Chromatography (HPLC)
Test Modes	Fast Mode, Variant Mode
Test Range	3% - 18%
Precision (CV)	＜2%
Parameter	HbA1c, HbF, HbA1a, HbA1b, HbA0, HbA2(Optional)
Test Speed	Fast Mode: 65 Seconds/Test
Sample Type	Whole blood, Pre-diluted blood
Sample Volume	Whole blood: 5μL Pre-diluted blood: 150μL
Sample loading capacity	110 tubes
Photometer	420nm/600nm
Column Capacity	3000T
Filter Capacity	600T
Display	10“ LCD touch screen
Reagent Kit	Eluent A, Eluent B, Eluent C, Hemolysis, Chromatography Column
Storage	10000 Sample Results
Connection interface	USB, LAN, LIS Compatible
Printer	Thermal Printer
System operation environment	Temperature 15-30℃ Humidity 30%-85%
Power	AC 100-240V 50/60HZ 300VA
Dimensions	768mmx600mmx570mm
Weight	≤50Kgs

HPLC Methodology

The system is made up by a high pressure HPLC pump, injector,column, detector. The mobile phase in the solution reservoir enters the injector via the HPLC pump, where it is mixed with the sample.Each component of the mixture passes through the chromatographic column at different rates, and each component flows out of the chromatographic column sequentially due to the different adsorption capacities between each component and the stationary phase in the chromatographic column.Then, the component concentration is converted into an electrical signal and transmitted to the HPLC software of the computer, and the generated waste liquid enters the waste liquid bottle. After the operation is completed, the chromatogram can be obtained in the HPLC software.

Performance

* HPLC- High Correlation with import HPLC

* CV<2% - Accurate and Stable

* Fast - Test speed is 65s/Test

* Full Automatated - Automated sample loading and barcode scanning
* Quality & Performance - IFCC & NGSP Certified

Reagents and Consumables

The analyzer is recommended to be used in conjunction with the Glycosylated Hemoglobin Test Reagent Kit (high performance liquid chromatography (HPLC method)) produced by our company, which includes the following components:

Eluent A/Eluent B/Eluent C(Variant Mode)	Adjusts the pH of the solution for the elution of glycosylated hemoglobin and non glycated hemoglobin.
Hemolysis Reagent	Used to dissolve red blood cells and release hemoglobin.
Chromatography Column	Used for separation and elution of glycosylated hemoglobin and non glycated.
Hemoglobin Filter	Used to initially filter the sample after hemolysis.
Paper Rolls	Prints a report of the test results.

Certificate
